What Fixings Fit a TentBox?

If you have ever opened a roof tent fitting bag and thought half of it looks familiar while the other half looks like it belongs to a different tent, you are not alone. One of the most common questions we hear is what fixings fit a TentBox, especially when owners are buying second-hand, replacing missing hardware, or upgrading to a more secure setup.

The short answer is that it depends on the TentBox model, the rail design underneath the tent, and the roof bars on the vehicle. There is no single universal fixing kit that fits every TentBox, every car, and every bar profile. That is exactly where people come unstuck. A fixing can look close enough on the garage floor and still be wrong once weight, vibration and road miles are involved.

What fixings fit a TentBox in practice?

In practice, most TentBox setups rely on a combination of mounting rails, brackets or plates, bolts, washers and nuts that clamp the tent base to the roof bars. The tent itself usually has aluminium rails or mounting channels underneath. The fixing hardware passes through or around those rails and then clamps onto the cross bars.

That sounds simple, but the details matter. Rail spacing varies. Cross bar height and width vary. Some bars are square, some are aero, some sit much taller than others, and some tents use different plate shapes or bolt lengths to get a safe grip. If a bolt is too short, you may only catch a few threads. If it is too long, it can foul the tent base or leave too much exposed hardware. Neither is ideal.

For many TentBox-style roof tents, the fixings people are usually talking about are the mounting brackets and bolts that secure the tent to the roof bars. In replacement terms, that often means a fixing kit with compatible brackets, suitable bolt length, matching washers, and nuts that fit the thread properly. If security is a concern, standard nuts can often be swapped for tamper-resistant alternatives, provided the thread and hardware dimensions match the original setup.

The main types of TentBox fixing hardware

There are a few common hardware types you will come across when working out what fixings fit a TentBox. The first is the basic mounting bracket arrangement. This usually consists of a plate above or below the mounting rail, a lower clamp section around the roof bar, and bolts joining the assembly together. It is the standard way to secure many rooftop tents.

The second is a sliding channel or rail-based system. On these tents, bolts may sit in the rail and slide to match the spacing of your roof bars. This gives more flexibility, but only if the bolt head or channel nut is the correct size for the rail.

The third is replacement rail hardware. If the original rails under the tent are bent, worn, cracked around the fixing points, or simply missing, replacing bolts alone will not sort it. You need to match the rail profile as well as the hardware.

Then there is the security side. Standard hex nuts are common, but they are also easy to remove with basic tools. A lot of owners move to locking or tamperproof security nuts once the tent is fitted. That does not change how the tent mounts, but it does change who can take it off quickly.

Why model and age matter

Not every TentBox uses the same mounting arrangement. Even within one brand, hard shell and soft shell designs can differ underneath. Older models may have different rail spacing or hardware dimensions compared with newer versions. A previous owner may also have mixed original parts with generic bolts from a hardware shop, which can make identification more awkward than it should be.

This is why asking for fixings "for a TentBox" is only a starting point. The useful questions are which TentBox model, what roof bars it is going on, whether the original rails are still fitted, and whether you want a like-for-like replacement or a more secure upgraded setup.

If you are buying used, check what is actually included rather than assuming the seller has supplied a complete fixing kit. Missing washers, mixed nuts, or bolts with damaged threads are common. So are cheap replacements that technically fit but do not give the clamping strength you want for a heavy roof tent.

How to check compatibility before buying

The safest way to work out what fixings fit a TentBox is to inspect three things - the tent rails, the roof bars, and the existing hardware.

Start under the tent. Look at the rail shape, the spacing between rails, and whether there are sliding bolts, channel nuts, or fixed mounting points. Then measure the roof bars. Width, height and shape all matter because the lower bracket or clamp must wrap them properly without sitting twisted or half-engaged.

After that, check the bolt diameter and thread pitch on the current hardware if you have it. This is where people often guess, and guessing is how stripped threads happen. A bolt can look right and still be the wrong thread. If you are replacing nuts with security nuts, the thread match has to be exact.

If your current setup already feels awkward to tighten, that is worth paying attention to. It may mean the bracket shape is not well matched to the bars, the bolts are too short, or the rail hardware is not original. A tent should clamp down firmly and evenly. You should not have one corner under tension while another still has movement.

Standard fixings versus security fixings

If your tent is already mounted correctly, you may not need a full replacement kit. Sometimes the real question is not what fixings fit a TentBox, but which security fixings can replace the standard nuts already on it.

That can be a smart upgrade. Roof tents are expensive, and the factory hardware on many setups is designed to mount the tent, not to slow down theft. Tamperproof security nuts keep the same mounting arrangement but make casual removal much harder. They are particularly useful if the tent stays on the vehicle full-time or is parked in public places, at trailheads, or on driveways.

There is a trade-off, though. Security hardware should still allow proper maintenance and removal when you need it. The best option is usually a purpose-made locking or tamper-resistant nut set that matches your existing fixing size rather than an improvised mix of odd fasteners.

Common mistakes when choosing TentBox fixings

The most common mistake is assuming all rooftop tent fixings are interchangeable. They are not. Plenty of brackets look similar online, but a few millimetres in bar height or bolt length can be the difference between a secure fit and a poor one.

Another mistake is focusing only on the tent and ignoring the roof bars. Your mounting hardware has to work with both. A bracket that fits the tent rail perfectly may still be wrong for deep aero bars or thick load bars.

The next issue is using generic stainless bolts without confirming strength, length and thread. Stainless can be useful in the right application, but not all bolts are equal, and not every shiny replacement is suitable for a heavy, vibrating load on top of a vehicle.

Finally, people often overlook wear in the rails themselves. If the rail channel is damaged, fresh nuts and bolts will not fix the underlying problem.

When a replacement kit makes more sense

If several parts are missing, mixed, rusted or chewed up, buying a proper replacement fixing kit is usually the cleaner option. It saves time, avoids hardware guesswork, and gives you matching parts designed to work together. That matters more than people think. A proper kit removes the small incompatibilities that lead to uneven clamping and repeated adjustments.

It also makes life easier if you want to add security at the same time. A compatible fixing and security setup is better than patching together standard brackets with whatever locking hardware you can find locally.

For owners who are not fully confident on identification, this is also where a specialist supplier or fitting service earns its keep. Roof Tent Security deals with these compatibility questions every day, and that is useful when your choices are not between good and better, but between correct and almost correct.

What to do if you are still unsure

If you cannot confirm the model, measure the rails and bars before ordering anything. Take clear photos of the underside of the tent, the roof bars, and the current hardware. That will usually tell you more than a vague description ever will.

If the tent was bought second-hand without fixings, do not rush into the cheapest universal kit you can find. Universal rarely means ideal in roof tent mounting. It usually means you still need to check dimensions carefully.

And if theft prevention is part of the job, build that into the plan from the start rather than as an afterthought. It is much easier to fit the right security nuts and compatible hardware once than to strip it all back later.

A roof tent only needs to come loose once, or disappear once, for the small details to feel very important. Get the fixings right, and the rest of the trip is a lot easier.
